(continued)
Using a 5/64" hex key remove the Spool cap and spring
(see fiGure 16.7)
needle-nosed pliers as shown in
the spool shaft using a cloth to wipe off any paint, debris
or old grease and lubricate all of the o-rings on the spool
shaft with Eclipse grease before re-inserting it
16.9)
. replace the Spool spring then Spool cap using a
5/64" hex key to secure them in place
hold the solenoid assembly onto the bottom of the Ego10
body taking care to line it up correctly with the screw
holes in the body and to avoid pinching the bbSS wires
underneath it. Use a 5/64" hex key to tighten the two
screws that hold the solenoid assembly onto the Ego10
body
(see fiGure 16.11).
you have now successfully stripped and cleaned your
Ego10 solenoid assembly.
62.
. remove the Spool shaft using a pair of
see fiGure 16.8
(see fiGure
(see fiGure 16.10)
. Clean
.
fiG 16.7
fiG 16.8
fiG 16.9
fiG 16.10
fiG 16.11
