PLANET ECLIPSE EGO TEN Operator's Manual page 64

(continued)
Note how one side of the exhaust valve guide is flat (A)
whilst the other is raised (b) to create the surface that
the exhaust valve seals on
the sealing face of both the exhaust valve guide and the
exhaust valve for any excessive wear or damage. if either
the exhaust valve or the exhaust valve guide are damaged
then replace with authentic Ego10 parts.
lubricate both of the o-rings on the exhaust valve guide
with Eclipse gun Oil
o-rings on the lPr body with Eclipse gun Oil
17.9).
Place the exhaust valve in the exhaust valve guide, making
sure that the sealing faces are next to each other, and place
the valve spring over the end of the exhaust valve and then
place this sub-assembly over the lPr body
17.10) .
note: MAKE SUrE ThE lArgEr DiAMETEr FrM SCrEw
hOlE ON ThE lPr bODy AND ThE blOCKED SiDE OF ThE
ExhAUST vAlvE gUiDE ArE iN liNE wiTh EACh OThEr
bEFOrE iNSErTiNg ThE PArT STACK iNTO ThE EgO10.
holding the lPr assembly so that the larger hole on the
lPr body is facing the bottom of the marker body, insert
the valve assembly, valve spring and lPr assembly into the
front of the marker body
64.
. inspect
(see fiGure 17.7)
(see fiGure 17.8) . lubricate the
(see fiGure
(see fiGure
.
(see fiGure 17.11)
a
b
fiG 17.7
fiG 17.10
fiG 17.8
fiG 17.9
fiG 17.11
