About the chip

About the chip
14
™
The QuantStudio 3D Digital PCR 20K Chip v2 is a 10-mm
plate that has a single array of 20,000 reaction wells. Hydrophobic coatings on the
chip surface enable loading and isolation of independent PCR reactions within the
wells.
Once loaded with a reaction, the chip must be sealed using the QuantStudio
Digital PCR Chip Lid v2 and filled with Immersion Fluid. Figure 2 shows the
components of the chip assembly.
1
2
3
Figure 2 QuantStudio ™
™
QuantStudio 3D Digital PCR Chip Lid v2—The lid used to seal the chip for thermal cycling
1
and imaging.
™
QuantStudio 3D Digital PCR 20K Chip v2—A 10-mm
2
the individual PCR reactions.
Chip case—The thermal-conductive base that secures and protects the chip.
3
Chip ID—A unique alphanumeric ID on the chip lid.
4
Fill port—The hole in the chip case lid through which Immersion Fluid is injected onto the
5
chip.
Reaction wells—The 20,000 physical holes on the surface of the chip that contain the
6
individual PCR reactions.
2D barcode—A barcode that encodes the same alphanumeric string as the Chip ID, scanned
7
™
by the QuantStudio 3D Digital PCR Instrument for chip tracking.
3D Digital PCR 20K Chip v2
QuantStudio
2
high-density reaction
5 7
4
2
chip with 20,000 wells that contain
™ 3D Digital PCR System User Guide
™
3D
6
