INVT Goodrive300-21 Series Operation Manual page 95

Goodrive300-21 series dual inverter integrated machine for air compressor
Function
instruction
SW 2 of the
inverter
Fault code of the
inverter
Identifying code of
the inverter
Operation
frequency
Setting frequency
Bus voltage
Output voltage
Output current
Operation speed
Output power
Output torque
Close loop setting
Close loop
feedback
PID setting
PID feedback
Input IO
Input IO
AI 1
AI 2
AI 3
AI 4
Read high speed
pulse 1 input
Address
definition
Bit0: =0:bus voltage is not established =1:bus
voltage is established
Bi1–2:=00:motor 1
=10:motor 3
Bit3: =0:asynchronous motor =1:synchronous
2101H motor
Bit4:=0:no overload pre-alarm;
=1:overload pre-alarm
Bit5– Bit6:=00: keypad control
=01:terminal control
=10:communication control
2102H See the fault type instruction
2103H GD300-21-----0x0129
3000H
3001H
3002H
3003H
3004H
3005H
3006H
3007H
3008H
Compatible with communication address of
3009H
CHF100A, CHV100
3008H
3009H
300AH
300BH
300CH
300DH
300EH
300FH
3010H
Data meaning instruction
=01:motor 2
=11:motor 4
- -
92
Appendix C
R/W
characteristic
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
