Goodrive300-21 integrated machine for air compressor
Function
Name
code
Communication
P14.06
processing action
Communication
P14.07 address of auxiliary
P17.00 Setting frequency
P17.01 Output frequency
Ramps reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor rotation speed 0–65535RPM
P17.06 Torque current
P17.07 Excitation current
P17.08 Motor power
P17.09 Output torque
Estimated motor
P17.10
frequency
P17.11 DC bus voltage
Digital input terminal
P17.12
state
Digital output terminal
P17.13
state
P17.16 Master fault code
P17.17 Fan fault code
P17.19 P1-input voltage
control modes)
0x00–0x11
LED ones: Writing operation acts
0: There is response for writing operation
1: No response for writing operation
LED tens: Communication encryption processing
0: Communication encryption is invalid
1: Communication encryption is valid
1–247, 0 is broadcasting add.
fan
0.00Hz–P00.03
0.00Hz–P00.03
0.00Hz–P00.03
0–1200V
0.0–3000.0A
-3000.0–3000.0A
-3000.0–3000.0A
-300.0%–300.0% (relative to rated motor power)
-250.0–250.0%
0.00– P00.03
0.0–2000.0V
0000–00FF
0000–000F
0–38 (see details at P07.27–P07.32)
0–38 (see details at P07.27–P07.32)
Display analog input voltage value of
P1-channel. 2.00V–10.00V corresponds to 4–
50mA. P05.32-P05.34 corresponds to pressure
0.0-P18.04. When P1-input voltage is detected to
be above 9.8V or below 1V, it is deemed as
pressure signal fault
Range: 0.00–10.00V
Detailed instruction
- -
42
Function instruction
Default
Modify
value
○
0x00
○
1
●
0.00Hz
●
0.00Hz
●
0.00Hz
●
0V
●
0.0A
●
0 RPM
●
0.0A
●
0.0A
●
0.0%
●
0.0%
●
0.00Hz
●
0V
●
0
●
0
●
0
●
0
●
0.00V
