Goodrive300-21 series dual inverter integrated machine for air compressor
A.1. Wall installation dimension
Fig A.1 Wall installation diagram for 220V 7.5–18.5kW/380V 15–37kW
Table A.1 Wall installation dimension for 220V 7.5–18.5kW/380V 15–37kW (unit: mm)
Inverter
specification
220V 7.5–11kW
380V 15–22kW
220V 15–18.5kW
380V 30–37kW
Fig A.2 Wall installation diagram for 220V 22–45kW/380V 45–90kW

Appendix A. Product dimension

W1 W2
250 210
300 210
H1 H2 H3
388 377
438 426
- -
68
Diameter of
D1
installation bore
7 170
8 190
Appendix A
6
6
