INVT Goodrive300-21 Series Operation Manual page 33

Goodrive300-21 integrated machine for air compressor
Function
Name
code
P04.35 Reactive closed-loop
integral coefficient
P05.00 Reserved
S1 terminal function
P05.01
selection
S2 terminal function
P05.02
selection
S3 terminal function
P05.03
selection
S4 terminal function
P05.04
selection
S5 terminal function
P05.05
selection
P05.06 Reserved
P05.10 Input terminal polarity This function code is used to set the polarity of
Detailed instruction
0–3000
Reserved
0: No function
1: Forward rotation running
2: Reverse rotation running
3: Three-wire running control
4: Forward rotation jogging
5: Reverse rotation jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10–24: Reserved
25: PID control pause
26–39: Reserved
40: Clear power consumption
41: Maintain power consumption
42: Air filter block signal
43: Oil filter block signal
44: Separator block signal
45: Splitter block signal
46: External fault 1
47: External fault 2
48: Fan running control signal
49: Solenoid valve control signal
50: Cooling fan control signal of main motor
51–63: Reserved
- -
30
Function instruction
Default
Modify
value
○
20
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
○
0x000
