Goodrive300-21 series dual inverter integrated machine for air compressor
Table A.2 Wall installation dimension for 220V 22–45kW/380V 45–90kW (unit: mm)
Inverter
specification
220V 22–45kW
380V 45–90kW
A.2. Floor installation dimension (with top cover)
Fig A.3 Floor installation (with top cover) for 220V 7.5–45kW/380V 15–90kW
Table A.3 Floor installation (with top cover) dimension for 220V 7.5–45kW/380V 15–90kW (unit: mm)
Inverter
specification
220V 7.5–11kW
380V 15–22kW
220V 15–18.5kW
380V 30–37kW
220V 22–45kW
380V 45–90kW
Note: Top cover must be selected together with the pedestal, namely floor installation (with top cover),
in addition, wall installation will be unavailable when installing the top cover.
W1 W2
370 220 330
W1
Front view
W1 W2
285 265
335 315
405 388
W3 H1 H2
590 572
Bottom view
H1 D1
623 205
682 225
884 285
- -
69
Diameter of
H3 D1
installation bore
9 250
Leftside view
Diameter of
D2 D3
installation bore
148 28
158 33
160 65
Appendix A
9
6
6
9
