INVT Goodrive300-21 Series Operation Manual page 36

Goodrive300-21 integrated machine for air compressor
Function
Name
code
P06.02 Reserved
P06.03 TAC1 output selection
P06.04 TAC2 output selection
Polarity selection of
P06.05
output terminal
Delay time of Y
P06.06
connection
Delay time of Y
P06.07
disconnection
P06.08 Reserved
P06.09 Reserved
Delay time of TAC1
P06.10
connection
Delay time of TAC1
P06.11
disconnection
Delay time of TAC2
P06.12
connection
Delay time of TAC2
P06.13
disconnection
P07.00 User password
P07.01 Copy of function
Detailed instruction
23: MODBUS communication virtual terminal
output
24–26: Reserved
27: Start/stop control of auxiliary motor (air
compressor-specific)
28: Solenoid valve control output (air
compressor-specific)
29: Cooling fan control of main motor (air
compressor-specific)
30: Reserved
This function code is used to set the polarity of
output terminals.
When the bit is set to 0, output terminal is
positive polarity;
When the bit is set to 1, output terminal is
negative polarity
BIT3 BIT2
TAC2 TAC1
Setting range: 0–0xF
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0–65535
0: No operation
- -
33
BIT1 BIT0
Reserved Y
Function instruction
Default
Modify
value
○
0
○
0
○
0
○
0
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0
◎
0x00
