INVT Goodrive300-21 Series Operation Manual page 94

Goodrive300-21 series dual inverter integrated machine for air compressor
Function
instruction
SW 1 of the
inverter
Address
definition
BIT4:=1 Clear the working time of part 5
=0: invalid
BIT5=1 Clear the working time of the device
=0: invalid
BIT6=1 Solenoid valve loading
=0: Solenoid valve unloading
The set time for maintenance on part 1;
2010H
range: 0–65535
The set time for maintenance on part 2;
2011H
range: 0–65535
The set time for maintenance on part 3;
2012H
range: 0–65535
The set time for maintenance on part 4;
2013H
range: 0–65535
The set time for maintenance on part 5;
2014H
range: 0–65535
2015H Working time of part 1; 0–65535
2016H Working time of part 2; 0–65535
2017H Working time of part 3; 0–65535
2018H Working time of part 4; 0–65535
2019H Working time of part 5; 0–65535
201AH Running time of the device; 0–65535
Command reference during fan debugging mode
0: No action
1: Running
201BH 2: Jogging
3: Stop
4: Coast to stop
5: Fault reset
Frequency reference during fan debugging mode;
201CH
range (0–1000, 1000 corresponds to 100.0%)
0001H: forward running
0002H: forward running
0003H: stop
2100H
0004H: fault
0005H: inverter POFF state
0006H: pre-exciting state
Data meaning instruction
- -
91
Appendix C
R/W
characteristic
W
W
W
W
W
W
W
W
W
W
W
R/W
R/W
R
