INVT Goodrive300-21 Series Operation Manual page 47

Goodrive300-21 integrated machine for air compressor
Function
Name
code
Running time of this
P17.26
P17.28 ASR controller output -300.0%–300.0% (rated motor current)
Magnetic pole angle of
P17.29
Phase compensation
P17.30
quantity of SM
P17.36 Output torque
P17.38 PID output value
Air compressor control
P18.00
mode
Sleep function
P18.01
selection
Loading/unloading
P18.02
mode
Temperature sensor
P18.03
channel
0–65535m
time
0.0–360.0
SM
-180.0–180.0
-3000.0Nm–3000.0Nm
Display PID control adjustment output value of
exhaust pressure signal. 100.0% corresponds to
maximum output frequency P00.03.
Setting range: -100.00–100.00%
0: Invalid
1: Air compressor control mode
Note: When P18.00=1, P19 group air
compressor state check group is valid
0: Invalid
1: Valid
Note: When sleep function is valid and unloading
condition is met, the inverter running frequency
decelerates to P18.12, after that, if the duration
time P18.13 of exhaust pressure is larger than
loading pressure P18.06, the inverter will
decelerate to stop speed P01.15 and then coast
to stop to enter sleep stage. If the exhaust
pressure is lower than loading pressure within
P18.13, the inverter will carry out loading
operation again and pressure PID will regulate
accordingly.
0: Automatic
1: Manual
If set to manual state, loading/unloading requires
manual operation after air compressor starts; if
set to automatic, load/unloading will be
conducted automatically according to the
pressure after air compressor starts.
0: head temperature PT1, auxiliary temperature
PT2
Detailed instruction
- -
44
Function instruction
Default
Modify
value
●
0m
●
0.0%
●
0.0
●
0.0
●
0.0Nm
●
0.00%
◎
0
◎
1
○
0
◎
0
