INVT Goodrive300-21 Series Operation Manual page 55

Goodrive300-21 integrated machine for air compressor
Function
Name
code
P19.13 Signal state 1
Detailed instruction
Current temp.
P18.03=0
150
P19.12
P18.28
0
-20
Current temp.
P18.03=1
150
P19.12
P18.32
0
-20
Range: -20–150℃
0000–0xFFFF
BIT0: Air filter block signal
1: Fault; 0: normal
BIT1: Oil filter block signal
1: Fault; 0: normal
BIT2: Separator block signal
1: Fault; 0: Normal
BIT3: Splitter block signal
1: Fault; 0: normal
BIT4: External fault signal 1
1: Fault; 0: normal
BIT5: External fault signal 2
1: Fault; 0: normal
BIT6: Solenoid valve signal state
1: Fault; 0: normal
BIT7: Auxiliary motor state
1: Run; 0: Stop
BIT8: Pressure pre-alarm signal
1: Pressure pre-alarm; 0: normal
BIT9: Temperature pre-alarm signal
1: Temperature pre-alarm; 0: normal
BIT10: Pressure alarm signal
1: Pressure alarm; 0: normal
BIT11: Temperature alarm signal
- -
52
P18.29
P17.20
PT1 input
voltage
P18.33
P17.22 PT2 input
voltage
Function instruction
Default
Modify
value
●
0
