Function Instruction; Function Code Instruction - INVT Goodrive300-21 Series Operation Manual

Goodrive300-21 integrated machine for air compressor
"○" : means the setting value of this parameter is modifiable when the inverter is in stop and running
state;
"◎": means the setting value of this parameter is non-modifiable when the inverter is in running state;
"●": means the value of this parameter is the actual detected record value and cannot be modified.
(The modification attribute of each parameter has been limited automatically to avoid mal-operation
by users.)

5.1. Function code instruction

Function
Name
code
P00.00
Speed control mode
Running command
P00.01
channel
Communication
P00.02
running command
channel selection
P00.03 Max. output frequency P00.04–600.00Hz (400.00Hz)
P00.04 Upper limit of running
frequency
P00.05 Lower limit of running
frequency

5. Function instruction

Detailed instruction
0: SVC 0 (suitable for AM, SM)
1: SVC 1 (suitable for AM)
2: V/F control
Note:
AM-asynchronous motor
SM-synchronous motor
If vector mode is adopted, it is necessary to carry
out motor parameter autotuning first.
0: Keypad running command channel (LED off)
1: Terminal running command channel (LED
flashes)
2: Communication running command channel
(LED on)
0: MODBUS communication channel
1–3: Reserved
P00.05–P00.03 (Max. output frequency)
Setting range: P00.06–P00.03
0.00Hz–P00.04 (upper limit of running
frequency)
- -
22
Function instruction
Default
Modify
value
◎
0
○
0
○
0
50.00H
◎
z
50.00H
○
z
○
0.00Hz
