Goodrive300-21 series dual inverter integrated machine for air compressor
B.6. Floor installation pedestal
B.6.1. Open package list
The default installation mode for Goodrive300-21 is wall installation. If Floor installation is needed,
users can install the pedestal for floor installation. The package list is shown as below:
Name
Combination screw
Pedestal
Note:
1. Refer to A.2 and A.3 for detailed dimensions.
2. If users select pedestal by themselves, please note that the ventilation hole size of the pedestal
should be no less than 1.2 times of the ventilation hole size at the bottom of integrated machine.
Model
M5×10
M8×16
278×170×180
328×190×180
404×250×240
- -
83
Qty. Remark
220V 7.5–18.5kW
380V 15–37kW
4
220V 22–45kW
380V 45–90kW
220V 7.5–11kW
380V 15–22kW
220V 15–18.5kW
1
380V 30–37kW
220V 22–45kW
380V 45–90kW
Appendix B
