Goodrive300-21 series dual inverter integrated machine for air compressor
Grounding of the shielded cable of
remote data collection terminal
Remote data collection
terminal
Secondary side of
current transformer
Grounding terminal
Current transformer
Front view of the
integrated machine
Fig B.19 Installation diagram of optional pedestal
Antenna
Connection
terminal
Through-hole of AC power
ground cable
R phase through-hole of
AC power
S phase through-hole of
AC power
T phase through-hole of
AC power
Fuse
- -
85
Leftside view of the
integrated machine
Appendix B
