INVT Goodrive300-21 Series Operation Manual page 44

Goodrive300-21 integrated machine for air compressor
Function
Name
code
(reserved)
High frequency
P13.06
overlay voltage
P13.08 Control parameter 1 0–FFFF
P13.09 Control parameter 2 0–300.00
Detection time of
P13.11
maladjustment
High frequency
P13.12 compensation
coefficient
Local communication
P14.00
address
Communication baud
P14.01
rate setting
P14.02 Data bit check setting
Communication
P14.03
response delay
Communication
P14.04
time-out fault time
Transmission error
P14.05
processing
Detailed instruction
0.0–300.0% rated motor voltage
Adjust the responsiveness of anti-maladjustment
function. When load inertia is large, increase this
value properly, but the responsiveness may
become slow consequently.
Setting range: 0.0–10.0s
This parameter is valid when the rotation speed
of the motor exceeds the rated value. If motor
oscillation occurred, adjust this parameter
properly.
Setting range: 0.0–100.0%
1–247, 0 is the broadcasting add.
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5 : 38400BPS
0: No check (N, 8, 1) for RTU
1: Even parity check (E, 8, 1) for RTU
2: Odd parity check (O, 8, 1) for RTU
3: No check (N, 8 , 2) for RTU
4: Even parity check (E, 8, 2) for RTU
5: Odd parity check (O, 8, 2) for RTU
0–200ms
0.0 (invalid), 0.1–60.0s
0: Alarm and coast to stop
1: Do not alarm and continue running
2: Do not alarm and stop in stop mode (only
under communication control mode)
3: Do not alarm and stop in stop mode (under all
- -
41
Function instruction
Default
Modify
value
◎
40.0%
○
0x120
○
5.00
○
0.5s
○
50.0%
○
2
○
4
○
1
○
5
○
0.0s
○
0
