INVT Goodrive300-21 Series Operation Manual page 32

Goodrive300-21 integrated machine for air compressor
Function
Name
code
motor 1
Torque elevator of
P04.01
motor 1
Torque elevation
P04.02
cut-off of motor 1
V/F frequency point 1
P04.03
of motor 1
V/F voltage point 1 of
P04.04
motor 1
V/F frequency point 2
P04.05
of motor 1
V/F voltage point 2 of
P04.06
motor 1
V/F frequency point 3
P04.07
of motor 1
V/F voltage point 3 of
P04.08
motor 1
V/F slip compensation
P04.09
gain of motor 1
Low frequency
P04.10 restraining vibration
factor of motor 1
High frequency
P04.11 restraining vibration
factor of motor 1
Restraining vibration
P04.12
cut-off point of motor 1
Energy-saving running
P04.26
selection
Weak magnetic
P04.33 coefficient of constant
power area
P04.34 Reactive closed-loop
proportional coefficient
Detailed instruction
1: Multi-point V/F curve
2: 1.3 power of torque reduction V/F curve
3: 1.7 power of torque reduction V/F curve
4: 2.0 power of torque reduction V/F curve
5: Reserved
0.0%: (automatic) 0.1%–10.0%
0.0%–50.0% (relative to rated frequency of motor
1)
0.00Hz–P04.05
0.0%–110.0% (rated voltage of motor 1)
P04.03– P04.07
0.0%–110.0% (rated voltage of motor 1)
P04.05–P02.02 (rated frequency of motor 1)
/P04.05–P02.16 (rated frequency of motor 1)
0.0%–110.0% (rated voltage of motor 1)
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (Max. output frequency)
0: No action
1: Automatic energy-saving running
1.00–1.30
0–3000
- -
29
Function instruction
Default
Modify
value
○
0.0%
○
20.0%
○
0.00Hz
○
00.0%
00.00H
○
z
○
00.0%
00.00H
○
z
○
00.0%
○
100.0%
○
10
○
10
30.00H
○
z
◎
0
○
1.00
○
100
