Goodrive300-21 series dual inverter integrated machine for air compressor
A.3. Floor installation dimension (without top cover)
Fig A.4 Floor installation (w/o top cover) for 220V 7.5–45kW/380V 15–90kW
Table A.4 Floor installation (w/o top cover) dimension for 220V 7.5–45kW/380V 15–90kW (unit: mm)
Inverter
specification
220V 7.5–11kW
380V 15–22kW
220V 15–8.5kW
380V 30–37kW
220V 22–45kW
380V 45–90kW
A.4. Product weight and packaging dimension
Product weight
220V 7.5–11kW/380V 15–22kW
(integrated machine)
220V 15–18.5kW/380V 30–37kW
(integrated machine)
220V 22–37kW/380V 45–75kW
(integrated machine)
220V 45kW/380V 90kW
(integrated machine)
W2
正视图
W1 W2
278 265
328 315
404 388
N.W(kg)
仰视图
H1 D1
555 180
604 190
812 250
G.W (kg)
15 18
22 24
38 42
42 45
- -
70
左视图
Diameter of
D2 D3
installation bore
148 10
158 15
160 44
Packaging dimension (mm)
515x385x320
585x435x340
725x490x410
725x490x410
Appendix A
6
6
9
