B.2.4. Dimension of contactor component
Fix this part with M4 screw
B.3. Power detection component and contactor component
When users need both power detection component and contactor component, the electrical diagram
is shown as below:
35mm standard guide rail installation
Fig B.9 Contactor dimension (unit: mm)
12
44.4
55.5
Fig B.10 Dimension of conversion terminals (unit: mm)
Fig B.11 Dimension of fuse pedestal (unit: mm)
M4 fixation screw
8
5
（ include dimension of transparent cover ）
- -
78
Appendix B
19.5
φ
4.5 installation bore
