INVT Goodrive300-21 Series Operation Manual page 38

Goodrive300-21 integrated machine for air compressor
Function
Name
code
P07.25 Factory bar code 5 0x0000–0xFFFF
P07.26 Factory bar code 6 0x0000–0xFFFF
P07.27 Current fault type
Detailed instruction
0: No fault
1: Inverter unit U phase protection (OUt1)
2: Inverter unit V phase protection (OUt1)
3: Inverter unit W phase protection (OUt1)
4: Overcurrent at acceleration (OC1)
5: Overcurrent at deceleration (OC2)
6: Overcurrent at constant speed (OC3)
7: Overvoltage at acceleration (OV1)
8: Overvoltage at deceleration (OV2)
9: Overvoltage at constant speed (OV3)
10: Bus undervoltage fault (UV)
11: Motor overload (OL1)
12: Inverter overload (OL2)
13: Phase loss on input side (SPI)
14: Phase loss on output side (SPO)
15: Overheat of rectifier module (OH1)
16: Overheat fault of inverter module (OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor autotuning fault (tE)
21: EEPROM operation fault (EEP)
22: PID feedback disconnection fault (PIDE)
23: Reserved
24: Running time up (END)
25: Electronic overload (OL3)
26: Panel communication error (PCE)
27: Parameter uploading error (UPE)
28: Parameter downloading error (DNE)
29–31: Reserved
32: Grounding short circuit fault 1 (ETH1)
33: Grounding short circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Maladjustment fault (STo)
36: Underload fault (LL)
37: Auxiliary fan fault (E_FAN)
- -
35
Function instruction
Default
Modify
value
●
●
●
