INVT Goodrive300-21 Series Operation Manual page 29

Goodrive300-21 integrated machine for air compressor
Function
Name
code
P02.19 Rated current of SM 1 0.8–6000.0A
Stator resistance of
P02.20
SM 1
D-axis inductance of
P02.21
SM 1
Q-axis inductance of
P02.22
SM 1
Counter electromotive
P02.23
force constant of SM 1
Overload protection
P02.26
selection of motor 1
Overload protection
P02.27
coefficient of motor 1
Detailed instruction
0.001–65.535Ω
0.01–655.35mH
0.01–655.35mH
0–10000
0: No protection
1: Regular motor (with low speed compensation)
2: Inverter motor (w/o low speed compensation)
Motor overload multiple M= Iout/(In*K)
In is rated motor current, lout is output current of
the inverter, and K is motor overload protection
coefficient.
The smaller the value of K, the larger the value of
M and the easier the protection.
When M=116%, protect when motor overload
lasts for 1 hour; when M=150%, protect when
motor overload lasts for 12 minutes; when
M=180%, protect when motor overload lasts for 5
minutes; when M=200%, protect when motor
overload lasts for 60 seconds; when M≥ 400%,
protect immediately.
- -
26
Function instruction
Default
Modify
value
Depend
◎
on
model
Depend
○
on
model
Depend
○
on
model
Depend
○
on
model
○
350
◎
2
○
100.0%
