Figure 3-20. Utility System Menu - Comtech EF Data SLM-3650 Installation And Operation Manual

SLM-3650 Satellite Modem
Operation
SLM3650 'TYPE'
VER: X.X.X
TIME: HH:MM:SS AM/PM
DATE: MM/DD/YY
Current time and date
OPERATION MODE
DUPLEX
TRANSMIT ONLY
RECEIVE ONLY
SELF TEST
OFF
AUTO
RUN
DISPLAY
CONTRAST
0 TO 100
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
FUNCTION SELECT UTILITY
UTILITY SYSTEM
REMOTE BAUD RATE
X PARITY
X =
150 2400
300 4800
600 9600
1200 19200
X = bps
Parity: even, odd, or none
TEST MODE STATUS
YEAR DISPLAY
2-DIGIT
INTRFC LOOPBACK
4-DIGIT
B-BAND LOOPBACK
CARRIER MODE
RX 2047 PATTERN
TX 2047 PATTERN
M&C FIRMWARE BOOT FIRMWARE
FW/NNNNNN-DDR
FW/NNNNNN-DDR
MM/DD/YYYY
BOOT FIRMWARE
F
Key:

Figure 3-20. Utility System Menu

3–62
REMOTE ADDRESS
1 to 255
LAMP TEST???
RS CORR OFF
Press [ENTER] to turn on all
the front panel indicators for
three seconds
RF LOOPBACK
IF LOOPBACK
FPGA FIRMWARE
FW/NNNNNN-DDR
FPGA FIRMWARE
MM/DD/YYYY MM/DD/YYYY
TURBO FIRMWARE
FW/NNNNNNR
VER: X.X.X
Only if Turbo Card is Installed
ACCESS CONDITIONAL OR
TO SUBMENU OPTION-DEPENDENT
Revision 3
MN/SLM3650.IOM
REMOTE TYPE
RS-485 (2-WIRE)
RS-485 (4-WIRE)
RS-232
Parameter Information
