SLM-3650 Satellite Modem
Operation
3.5.1.7
SDM-100 Emulation Operation
The SDM-100 Emulation feature of the modem provides remote protocol compatibility
with existing SDM-100 modems, which makes several applications possible:
•
Add an SLM-3650 to a rack of SDM-100s with a protection switch.
•
Replace an SDM-100 requiring service with SLM-3650.
•
Use SLM-3650 as the backup modem for a rack containing a mix of SDM-100
and SLM-3650 modems.
SDM-100 Emulation is typically a closed network application, with no added overhead.
The modem does not require any additional hardware to operate in SDM-100 Emulation.
The basic modem configuration, which includes the 25-pin D Data I/O connector,
supports V.35, EIA-422, and EIA-232-C data.
Refer to Table 3-10 for SDM-100 emulation parameter settings.
Table 3-10. SDM-100 Emulation Parameter Settings
Parameter
Modem Emulation
TX Data/Code Rate
TX IF Output
RX Data/Code Rate
TX Clock Source
Buffer Clock Source
Modulator Type
Encoder Type
Demodulator Type
Decoder Type
TX Overhead Type
RX Overhead Type
Interface Type
Buffer Program
RTS TX IF Cntrl
Note: Refer to Appendix A, A.1.4, for more information on the asynchronous interface with
AUPC.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Front Panel Settings
SDM-100
TX-V, QPSK 1/2
ON
RX-V, QPSK 1/2
TX Terrestrial
Satellite Clock
INTELSAT Open, CSC Closed, FDC
Closed, EFD Closed
Viterbi or Sequential
INTELSAT Open, CSC Closed, FDC
Closed, EFD Closed
Viterbi or Sequential
None
None
EIA-422, EIA-232, V.35
Bits or Milliseconds
OFF or ON
3–85
MN/SLM3650.IOM
Reference Menu
Utility: Modem Type
Configuration; Modulator
Configuration: Modulator
Configuration: Demodulator
Configuration: Interface
Configuration: Interface
Utility: Modulator
Utility: Modulator
Utility: Demodulator
Utility: Demodulator
Utility: Interface
Utility: Interface
Utility: Interface
Utility: Interface
Utility: Interface
Revision 3
