SLM-3650 Satellite Modem
Operation
SERVICE CHANNEL ADJUST
DROP FORMAT
INSERT FORMAT
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This configuration function is used to set service channel audio levels at
TX-1, TX-2, RX-1, or RX-2.
Upon entry, press [←] or [→] to select the desired service channel. To adjust the service
channel level (+10.0 to -20.0 dBm), press [ENTER]. Press [↑] or [↓] to adjust the service
channel. Press [ENTER] to execute the change.
Conditional: This menu is only available when IDR has been selected for modem type in the
Utility menu and the Overhead Card is installed.
This configuration is used to select the desired drop data channel signaling. The choices are:
E1_CCS (E1 Common Channel Signaling)
E1-CAS (E1 Channel Associated Signaling)
E1_31_TS (E1 No Multiframe Sync Alignment)
T1 (T1 Data)
T1_ESF (T1 Extended Super Frame)
T1_ESF_S (Special Signaling)
T1_S (Special Signaling)
Upon entry, the current drop data channel signal is displayed. Press [↑] or [↓] to make the
selection. Press [ENTER] to execute the change.
Conditional: This menu is only available when the optional D&I has been selected for Modem
Type in the Function Select: Utility menu and the Overhead card is installed.
Selects the desired insert data channel signaling. The choices are:
E1_CCS (E1 Common Channel Signaling)
E1-CAS (E1 Channel Associated Signaling)
E1_31_TS (E1 No Multiframe Sync Alignment)
T1 (T1 Data)
T1_ESF (T1 Extended Super Frame)
T1_ESF_S (Special Signaling)
T1_S (Special Signaling)
Upon entry, the current insert data channel signal is displayed. Press [↑] or [↓] to make the
selection. Press [ENTER] to execute the change.
Conditional: This menu is only available when the optional D&I has been selected for Modem
Type in the Function Select: Utility menu and the Overhead card is installed.
3–22
Revision 3
MN/SLM3650.IOM
