SLM-3650 Satellite Modem
Operation
RX CHAN # 3 MODE
RX CHAN # 3 DR
RX CHAN # 3 PHASE
RX CHAN # 4 MODE
RX CHAN # 4 DR
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Programs the RX Channel # 3 MODE.
ASYNC RS232
SYNC RS232
ASYNC RS422
SYNC RS422
AUPC
Disabled
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement the selected
kbps. Press [ENTER] to execute the change.
Programs the RX Channel # 3 DR
SYNC RS422:
0.6 to 4000.0 kbps
All other modes:
0.6 to 64 kbps
Note: Not displayed if AUPC or Disabled is selected.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement the selected
kbps. Press [ENTER] to execute the change.
Programs the RX # 3 PHASE.
NRM or INV
Note: Not displayed if AUPC or Disabled is selected.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement the selected
kbps. Press [ENTER] to execute the change.
Programs the RX Channel # 4 MODE.
ASYNC RS232
SYNC RS232
ASYNC RS485
AUPC
Disabled
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement the selected
kbps. Press [ENTER] to execute the change.
Programs the RX Channel # 4 DR.
0.6 to 64 kbps
Note: Not displayed if AUPC or Disabled is selected.
Press[←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement the selected
kbps. Press [ENTER] to execute the change.
3–35
Revision 3
MN/SLM3650.IOM
