Table A-2. D&I Specification - Comtech EF Data SLM-3650 Installation And Operation Manual

SLM-3650 Satellite Modem
Options
A.1.3.1 D&I Specifications
Refer to Table A-2 for D&I specifications.
Parameter
Primary Data Circuits Supported
Primary Data Rates Supported
Satellite Data Rates Supported
Terrestrial Framing Supported
Satellite Overhead Rate
Drop Time Slot Selection
(Time Slot 0 not Allowed)
Insert Time Slot Selection
(Time Slot 0 not Allowed)
Interface Type
Terrestrial Input Data Rate
Pulse Width
SD Amplitude
RD Amplitude
Pulse Mask
Line Code
Jitter Attenuation
Transmit Clock Reference
Plesiochronous Buffer
Buffer Clock Reference
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table A-2. D&I Specifications
Specification
T1 DSD, DRD, ISD, IRD
E1 DSD, DRD, ISD, IRD
1544 kbps per G.703
2048 kbps per G.703
N x 64 kbps
N = 1, 2, 3, 4, 5, 6, 8, 10, 12, 15, 16, 20, or 24 (T1)
N = 1, 2, 3, 4, 5, 6, 8, 10, 12, 15, 16, 20, 24, or 30 (E1)
G.732/G.733, G.704
1/15 of data rate per IESS-308 Rev. 6 and IESS-309 Rev. 3
1 to 24 (T1)
1 to 31 (E1)
Arbitrary order
1 to 24 (T1)
1 to 31 (E1)
Arbitrary order
Transformer coupled symmetrical pair
T1 1544 kbps ± 100 bit/s
E1 2048 kbps ± 130 bit/s
T1 324 ± 50 ns
E1 244 ± 25 ns
T1 3.0 +0.3/-1.5 V-pk into 100Ω
E1 3.0 +0.3/-1.5 V-pk into 120Ω
T1 3.0 ± 0.3 V-pk into 100Ω
E1 3.0 ± 0.3 V-pk into 120Ω
T1 G.703.2
E1 G.703.6
Selectable AMI, B8ZS, HDB3
T1, per AT&T 43802
T1, per CCITT G.824
E1, per CCITT G.823
Normal (derived from drop SD)
Internal (10-5 accuracy)
External (EIA-422 input)
Included in receive path
Derived from insert input
External (EIA-422)
Internal
A–8
Revision 3
MN/SLM3650.IOM
