SLM-3650 Satellite Modem
Installation
2.3.3.1.1 Data I/O Connector (J8) Removal
1. (For Ribbon-Configured Connector PL/6031.) Remove Data I/O connector (J8)
(Figure 2-7) as follows:
a. Remove four screws securing the rear panel to the chassis.
b. Pull out rear panel to gain access to disconnect connector (J8).
c. Disconnect connector (J8) from the PCB.
d. Remove the four screws securing connector (J8) to the rear panel.
e. Remove the connector (J8).
2. (For Part No. PL/5509-1.) Remove 50-pin Data I/O connector (J8) as follows:
a. Remove the four screws securing the connector (J8) to the rear panel.
b. Establish a grip on connector (J8) and pull backwards until separation of the
c. Remove connector (J8).
2.3.3.1.2 Data I/O Connector (J8) Installation
1. (For Ribbon-Configured Connector PL/6031.) Install Data I/O connector (J8)
(Figure 2-7) as follows:
a. Position connector (J8) in rear panel.
b. Connect connector (J8) to the PCB.
c. Secure connector (J8) to the rear panel with four screws.
d. Position the rear panel to mate with the chassis and secure with four screws.
2. (For Part No. PL/5509-1.) Install 50-pin Data I/O connector (J8) as follows:
a. Connect connector (J8) to the PCB.
b. Secure connector (J8) using four screws.
