SLM-3650 Satellite Modem
Options
A.1.4.5.1 Configuration #1 (Local EIA-232 to Remote EIA-232)
#1. Local End Modem Settings for EIA-232
Utility: Interface Menu
ASYNC TX and RX Type
Configuration: Interface Menu
ASYNC TX and RX Baud Rate
ASYNC TX and RX Length
ASYNC TX and RX Parity
ASYNC TX Stop
#1. Remote End Modem Settings for EIA-232
Utility: Interface Menu
ASYNC TX and RX Type
Configuration: Interface Menu
ASYNC TX and RX Baud Rate
ASYNC TX and RX Length
ASYNC TX and RX Parity
ASYNC TX Stop
Utility: System Menu
Remote Baud Rate
Parity
Address
The local end cable connects the 25-pin female ASYNC connector (on either the
breakout panel or the Y cable) to the EIA-232 remote terminal (WYSE or laptop
computer). The pinout of the local cable is listed in the following table.
The remote end cable connects the 25-pin female ASYNC connector (on either the
breakout panel or the Y cable) to the 9-pin female connector, J6, at the rear of the
modem. The pinout of the remote cable is listed in the following table.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table A-5. Local EIA-232 to Remote EIA-232

EIA-232
150 to 38400
7 bits
Even
2 bits
EIA-232
150 to 38400
7 bits
Even
2 bits
Equal to ASYNC TX and RX baud rate
Even
1 to 255
#1. Local End EIA-232
9-Pin
Female Connector
RX 2
TX 3
GND 5
#1. Remote End EIA-232
9-Pin
Male Connector
RX 2
TX 3
GND 5
A–31
(See A.1.4.3.10)
(See A.1.4.3.10)
25-Pin
Male Connector
3 TX
2 RX
7 GND
25-Pin
Male Connector
2 RX
3 TX
7 GND
Revision 3
MN/SLM3650.IOM
