SLM-3650 Satellite Modem
Operation
SLM3650 "TYPE"
VER: X.X.X
ASSIGN TX
FILTER
See Description Table.
ENCODER TYPE
VITERBI
SEQUENTIAL
TURBO
TX-RS DUPLEX
N=225 K=205 I=8
R-S DUPLEX
INSTALLAED ONLY
Note: ALternate to TX-RS
INTERLEAVE
TX SYMBOL RATE
4.8 tp 2500 ksps
(Status only)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
FUNCTION
SELECT UTILITY
MOD POWER OFFSET
-99.9 to +99.9 dB
in 0.1 dB steps
TX BPSK ORDERING
STANDARD
NON-STANDARD
TX-R-S DUPLEX
DEFAULT
R-S DUPLEX
INSTALLED ONLY
TX MODE
CONTINUOUS or
BURST
Figure 3-17. Utility Modulator Menu
3–52
UTILITY
MODULATOR
SINGLE RATE
DATA RATE
(Modems Only)
MODULATOR TYPE
INTELSAT OPEN
CSC CLOSED
FDC CLOSED
SDM51 COMPATIBLE
EFD CLOSED
MOD SPECTRUM
NORMAL
INVERT
TX R-S INSTALLED ONLY
TX-IESS-310 MODE
TX IESS-315 MODE
ON
OFF
(TURBO Only)
Key:
CONDITIONAL OR
ACCESS TO
SUBMENU
OPTION DEPENDENT
-
Revision 3
MN/SLM3650.IOM
UTILITY
TX-RS INTERLEAVE
4, 8, 16 DEEP
ON
OFF
