Introduction

This chapter supplies troubleshooting and fault isolation information for the Controller
and the Intensifier. Use the troubleshooting charts to isolate problems.

Controller Troubleshooting

Use the information in the subsequent sections to troubleshoot the Controller.

Controller Fault Codes

Code
Description
Number
01 IEEE port failure
02 Printer interface failure
Pressure transducer
21
interface failure
22 Logic chip failure
User data EEPROM
23
corrupted
31 User data memory failure
32 Time or date clock failure
User data lost or
33
corrupted
34 System memory failure
35 Host interface failure
Internal device interface
36
failure
1. Fault codes 01 and 02 indicates problems with the comm
board pca. To clear the fault:
2. Check cable that connects to the comm pca to the main
pca and try action again.
3. Turn off the Controller and disconnect and reconnect the
cable connecting the comm pca to the main pca and cycle
power.
4. Replace the wire that connects to the comm pca to the
main pca.
5. Replace comm pca. See Chapter 4 for Controller part
replacement procedures.
Fault codes 21 through 23 indicate problems with the main pca.
To clear the fault, reset from on-screen error message and try
again. If the reset does not clear the fault, replace the main pca
and try again. See Chapter 4 for Controller part replacement
procedures.
Fault codes 31 through 36 indicate problems with the
microprocessor pca. If any of these faults show, there is a
problem with the microprocessor pca and it must be replaced to
clear the fault. See Chapter 4 for Controller part replacement
procedures.
