Spares Kit Assembly (Not Shown) - Fluke Calibration 4322-SYS-NAVAIR Service Manual

4322
Service Manual
O-RING, URETHANE, 14 MM ID X 1 MM C/S, PU90 DURO
YELLOW, COMPOUND # U9001Y
O-RING, URETHANE, 12 MM ID X 1 MM C/S, PU90 DURO
YELLOW, COMPOUND # U9001Y
O-RING, URETHANE, 8 MM ID X 1 MM C/S, PU90 DURO
YELLOW, COMPOUND # U9001Y
O-RING, FLUOROCARBON, SHORE A 75, BLK, AS 568A-
014, 0.489 ID, 0.070 W, ROHS COMPL.
48547, BUSHING NON-RIBBED
O-RING, CAST URETHANE, 90 DURO, 003 (0.060 W X 0.056
ID)
SEAL ASSEMBLY, HIGH PRESSURE, T61 SEAL /P02
BACKUP RING /FKM O-RING
O-RING, URETHANE, 3.5 MM ID X 1 MM C/S, PU90 DURO
YELLOW, COMPOUND # U9001Y
DECAL, SPARE PARTS CASE
CASE, ABS, 3.875 IN X 2.375 IN X 1.375 IN, WITH HANDLE,
BLACK
FUSE 5X20 5A S/B 250V
4322-5933, CUT DETAIL, COALESCING FILTERS
FUSE, FUSE, 5X20 MM,1 A, 250 V, SLOW
WRENCH, INTENSIFIER PISTON
TOOL, PISTON INSERTION, 4322
FILTER, METAL
O-RING, POLYURETHANE, 90 DURO, 1 MM W X 2 MM ID,
TRANSLUCENT
O-RING, SILICON, 3 MM W X 13 MM ID, 70 DURO, RED-
ORANG
7-8
Table 7-4. Spares Kit Assembly (not shown)
Description Part Number Quantity
4398685 1
4398697 1
4398703 1
2527053 2
2213849 2
4261927 9
4338494 4
4398715 2
4179300 1
4184213 1
2077364 1
4358838 2
808055 1
4225996 1
4367097 1
4155812 1
4326327 6
4404489 1
Notes
