Measurement Specifications; Pressure Control Specifications - Fluke Calibration 4322-SYS-NAVAIR Service Manual

4322
Service Manual
Name
Test hoses, 3 m (10 ft)
Interconnect hose, 1.8 m (6 ft)
Supply hose, 1.8 m (6 ft)
Notes:
1. IQC70 is a Fluke Calibration interlocking quick connection nominally rated to 70 MPa (10,000 psi).
2. Hose limited to 3,000 psi due to miniature QC used to connect to the fitting on the regulator.

Measurement Specifications

Barometer Module Range .................................... 70 kPa to 110 kPa absolute (10 psi to 16 psi) absolute
Pressure Transducer Module Ranges
Note: Pressure modules are switched automatically and transparently to the operator.
A150k .................................................................. 3.5 kPa to 150 kPa absolute (0.5 psi to 22 psi)
G700k ................................................................. 50 kPa to 700 kPa gauge (7 psi to 100 psi)
G10M .................................................................. 700 kPa to 10 MPa gauge (100 psi to 1,500 psi)
G70M .................................................................. 10 MPa to 70 MPa gauge (1,500 psi to 10,000 psi)
Resolution ............................................................. Greater of 0.001% of reading or 0.00004 psi (0.28 Pa)
Measurement
Mode
[2]
Gauge
Absolute
[2]
Vacuum
Notes:
1. Measurement uncertainty is defined as the maximum deviation from the indicated value of measured pressure for 1 year
after alignment including hysteresis, linearity, repeatability, stability, temperature, humidity effects, and calibration reference
standard measurement uncertainty. Expression of uncertainty uses a coverage factor of 2 and conforms with the
recommendations of the ISO Guide to the Expression of Uncertainty in Measurement.
2. Negative gauge and vacuum pressure values assume the ambient atmospheric pressure is approximately 101 kPa
(14.7 psi) absolute.

Pressure Control Specifications

Control Precision .................................................. Greater of ± 0.025 % of reading or ± 25 Pa (0.0036 psi).
Pressure Source
On-board Pump
External Gas
Supply
Note:
1. Negative gauge and vacuum pressure values assume the ambient atmospheric pressure is approximately 101 kPa
(14.7 psi) absolute.
1-8
Type of Fittings
IQC70 male stem at one end, and
IQC070 female coupling at the other.
IQC70 male stem at both ends.
IQC70 male stem at one end, and
miniature QC male stem at the other.
Measurement Uncertainty
Range
-98 kPa to +28 kPa (-14.2 psi to +4 psi) gauge
28 kPa to 70 MPa (4 psi to 10,000 psi) gauge
3.5 kPa to 130 kPa (0.5 psi to 19 psi) absolute
130 kPa to 70 MPa (19 to 10,000 psi) absolute
0 kPa to 98 kPa (0 to 14.2 psi, 0 to 29 inHg)
Measure Mode
[1]
Gauge
Absolute
Vacuum (negative gauge)
Gauge
Absolute
High-Pressure Hoses
[1]
±25 Pa (0.0036 psi, 0.1 in H
±0.1 % of reading
±25 Pa (0.0036 psi, 0.1 in H
±0.1 % of reading
±25 Pa (0.0074 inHg)
Control Ranges
-98 kPa to 2 MPa (-14.2 to 300 psi)
3.5 kPa to 2 MPa (0.5 to 300 psi)
[1]
0 to 98 kPa (0 to 14.2 psi, 0 to 29 inHg)
28 kPa to 70 MPa (4 to 10,000 psi)
130 kPa to 70 MPa (19 to 10,000 psi)
Maximum Working Pressure Limit
70 MPa (10,000 psi)
70 MPa (10,000 psi)
[2]
20 MPa (3,000 psi)
[1]
Uncertainty
O at 20 °C)
2
O at 20 °C)
2
Range
