Bearing Installation Depth in Planet Gears
Bearing Pin
Bearings
0.70 mm
1.70 mm
Larger Chamfer on Clip Side
2
Planet Gear
7
Figure 5-8. Planetary Gear Replacement
1
3
4
5
6
8
9
10
Intensifier Maintenance
Intensifier Part Replacement
hbx020.eps
5
5-23
