Fluke Calibration 4322-SYS-NAVAIR Service Manual page 155

Ref.
H1 SURGE NIPPLE
H2 BALL
H3 SURGE VALVE CUP
FINE FILTER COALESCING FILTER PACK - 30 MM
H4
AND 20 MM LONG FILTERS
H5 DUT TUBE
H6 M1.6 X 5 SHCS
H7 UPPER FILTER DISK
H8 FILTER DISK GASKET
H9 LOWER FILTER DISK
H10 PURGE TUBE
H11 COARSE FILTER METAL FILTER
H12 LOWER FILTER RETAINER
H13 O-RING
H14 FILTER HOUSING
H15 FILTER RETAINER
H16 O-RING
H17 METAL FILTER
H18 O-RING
H19 MOUNT
H20 WASTE CONTAINER SEAL
H21 M6 FLAT WASHER
H22 1/4 – 28 HEX NUT
H23 TAPERED SPRING
Table 7-10. A15 CPS Assembly
Description
List of Replaceable Parts
Part Number Quantity
4255160 1
3474441 1
4255149 1
4358838 1
4155835 1
4219120 3
4155755 1
4155770 1
4155762 1
4155820 1
4155812 1
4155587 2
4320809 1
4155579 1
4255124 1
4261793 1
4271434 1
4261779 1
4255092 1
4155796 1
3134319 1
4218576 1
4218565 1
Controller Final Assembly
Notes
7
7-19
