Required Equipment

The equipment in Table 3-1 is required to complete the calibration procedure.
Classifications
Automated Pressure
Calibrator (APC)
Pressure Controller
CPS module
(Contamination
Prevention System)
Cylinder hose
Intensifier outlet hose
Test hose
Reference pressure
standard
Nitrogen Supply
IEEE cable

Environmental Conditions

Laboratory environmental conditions required to complete this procedure:
•
•
•
3-4
Table 3-1. Calibration Equipment
Minimum Use Specifications
See Required Components
Range: 0.5 psia to 10,000 psia
(-14.2 to 10,000 psig)
Fluke 4322 required
Clean and dry.
10,000 psi, Fluke 4322 QC stem
10,000 psi, Fluke 4322 QC stem
10,000 psi, Fluke 4322 QC stem, King
Nutronics QC stem
Gauge pressure:
0 to 4 psig: ±0.001 psi
4 to 10,000 psig: ±0.025 % of reading
Vacuum Pressure:
0 to 30 inHg: ±0.025 % of reading or
±0.002 in-Hg, whichever is greater
Absolute Pressure:
0.5 to 35 inHga: ±0.002 inHg
17.2 to 10,000 psia: ±0.025 % of reading
Clean, dry, minimum 500 psig
Standard: IEEE-488.2
Minimum length: 2 ft
Ambient temperature range: 60 °F to 85 °F. Must not change more than ± 4 °F
throughout the calibration.
Ambient relative humidity: 5 % to 95 %. Must not change more than ±20 % RH
throughout the calibration.
Low wind and draft area.
Primary Reference
Suggested Equipment
Supplied with Fluke 4322
Supplied with Fluke 4322
Supplied with Fluke 4322
Supplied with Fluke 4322
Supplied with Fluke 4322
Supplied with Fluke 4322
King Nutronics 3689 or
equivalent
Nitrogen Cylinder
Supplied with Fluke 4322
