Item Description
A1 INTENSIFIER PCA
A2 POWER SUPPLY PCA
A3 MOTOR CONTROLLER
A4 POWER ENTRY MODULE
H1 M3 X 6 SHCS
H2 M3 LWASH
H3 M3 X 30 STANDOFF
H4 KNOB
H5 HANDLE
H6 WASHERS
H7 M4 X 10 SHCS
H8 M4 LWASH
H9 BRACKET
H10 M5 LWASH
H11 M5 X 12 SHCS
H12 3/8 CABLE CLAMP
H13 M4 FLAT WASHER
H14 M4 X 10 SHCS
H15 M4 HEX NUT
H16 M4 EXT LWASH
H17 M3 HEX NUT
H18 M3 FLAT WASHER
H19 M3 EXT LWASH
H20 ¼ IN CABLE CLAMP
H21 CONTRACT MFG ITEM, FUSE 5X20 5 A S/B 250 V
Table 7-13. A1 Control Panel Assembly (Page 2)
List of Replaceable Parts
Part Number Quantity
4142630 1
4369947 1
4212180 1
4341311 1
3154248 8
3153752 8
3140491 4
3337089 2
4340703 2
4334721 4
3153272 2
3153914 2
4139451 1
3154144 4
4058169 4
3988269 2
3153079 1
3153272 1
3153147 2
3168103 2
2678004 4
3152972 4
3153135 1
3138271 1
2077364 2
Intensifier Final Assembly
Notes
7
7-25
