Icm And Shaft Assembly - Fluke Calibration 4322-SYS-NAVAIR Service Manual

4322
Service Manual
Item
A1 ICM ASSEMBLY
A2 PISTON & CLEVIS ASSEMBLY
H1 O-RING
H2 PRESSURE PORT SHAFT
H3 CYLINDER RETAINING NUT
H4 CYLINDER HOUSING
O-RING,URETHANE, 3.5 MM ID X 1 MM C/S, PU90
H5
DURO YELLOW, COMPOUND # U9001Y
O-RING,URETHANE, 14 MM ID X 1 MM C/S, PU90
H6
DURO YELLOW, COMPOUND # U9001Y
7-32
Table 7-17. ICM and Shaft Assembly
Description
H4
Figure 7-16. ICM and Shaft Assembly
Part Number Quantity
4217558
4217564
2527053
4136175
4181212
4136244
4398715
4398685
H1
H2
H1
A1
H3
H5
H6
Note
4
4
2
1
4
1
4
4
A2
hbx047.eps
