7. Select . This starts the Alignment procedure.
3-10
The Alignment procedure is an automated process. The Controller automatically sets
pressure, dwells, and takes measurements. As the test runs, the Controller reads the
measurements from the modules and receives measurements data from the KN 3689
over the GPIB connection. The measurements are compared by the Controller. When
the Alignment procedure is complete, a new screen will appear that shows the test
results with deviation calculations. To finalize the Alignment, select "Activate" on
the bottom of the menu to save the new coefficents to the module. The Alignment
procedure is now complete. Calibration should be performed to verify that the
aligned range meets measurement tolerances.
