Fluke Calibration 4322-SYS-NAVAIR Service Manual page 163

Item
A1 ENCODER PCA
A2 PUMP CAM ASSEMBLY
A3 CAM PLATE & PLANET GEARS ASSEMBLY
H1 M4 X 12 SHCS
H2 M4 LOCK WASHER
H3 UPPER SHAFT MOUNT PLATE
H4 C-CLIP
H5 M3 X 8 SHCS
H6 M3 LOCK WASHER
H7 ENCODER MOUNT PLATE
H8 M3 X 6 BHSHC
H9 M3 X 10 SHCS
H10 PLATE, COVER, INTENSIFIER
Notes:
[1] – Part can be damaged by static discharge. Use proper electrostatic discharge (ESD) procedures.
[2] – Not orderable as a complete assembly.
Table 7-14. A2 Booster Pump Assembly
Description
List of Replaceable Parts
Part Number Quantity
4213347 1
- 1
- -
3153285 4
3153914 4
4139956 1
4218936 1
3153249 2
3153752 12
4140079 1
3154677 2
3153224 8
4388491 1
Intensifier Final Assembly
Notes
[1]
[2]
[2]
7
7-27
