Item
A1 ICM & SHAFT ASSEMBLY
A2/A3 CAM PLATE & PLANET GEARS ASSEMBLY
H1 M3 X 10 SHCS
H2 M3 LOCK WASHER
H3 M4 X 12 SHCS
H4 M3 X 8 FLAT HEAD
H5 CAM MOUNT PLATE
H6 SHAFT/BEARING HUB
H7 BEARING
H8 WAVE SPRING
H9 PISTON GUIDE PLATE
H10 PISTON GUIDE RAIL
H11 CAM
H12 PISTON GUIDE RAIL SPACER
H13
102668-Z, WASHER, LOCK, SPLIT, STAINLESS, M4
Note
[1] – Entire assembly is not orderable.
Table 7-15. A2/A2 Pump Cam Assembly
Description
List of Replaceable Parts
Part Number Quantity
- -
- -
3153224 56
3153752 56
3153285 8
4212956 32
4136182 1
4136271 2
4212638 2
4212645 2
4136259 2
4145987 16
4136153 1
4145993 8
3153914 8
Intensifier Final Assembly
Notes
[1]
[1]
7
7-29
