Operating Guide | VLT® AutomationDrive FC 302
1-76
1-71
Start (18)
Start
reversing (19)
Relay output
Open
Closed
Illustration 44: Mechanical Brake Control

7.1.14 Wiring Configuration for the Encoder

The direction of the encoder, identified by looking into the shaft end, is determined by which order the pulses enter the drive.
• Clockwise (CW) direction means channel A is 90 electrical degrees before channel B.
• Counterclockwise (CCW) direction means channel B is 90 electrical degrees before A.
A
B
A
B
Illustration 45: Determining Encoder Direction
Maximum cable length is 5 m (16 ft.)
94 | Danfoss A/S © 2019.12
2-21
1-71
1
2
N O T I C E
Wiring Configuration Examples
Time
2-21
AQ275652476278en-000101 / 130R0709
Current
Speed
