Operating Guide | VLT® AutomationDrive FC 302
Q2 Quick Setup
The parameters found in the Q2 Quick Setup contain basic system and motor data that are always necessary for configuring the drive.
See 6.3.3 Entering System Information
Q4 Smart Setup
Q4 Smart Setup guides the user through typical parameter settings used to configure 1 of the following 3 applications:
• Mechanical brake.
• Conveyor.
• Pump/fan.
The [Info] key can be used to see help information for various selections, settings, and messages.
Q5 Changes Made
Select Q5 Changes Made for information about:
• The 10 most recent changes.
• Changes made from default setting.
Q6 Loggings
Use Q6 Loggings for fault finding. To get information about the display line readout, select Loggings. The information is shown as
graphs. Only parameters selected in parameter 0-20 Display Line 1.1 Small through parameter 0-24 Display Line 3 Large can be viewed. It
is possible to store up to 120 samples in the memory for later reference.
Table 8: Logging Parameter Examples
Q6 Loggings
Parameter 0-20 Display Line 1.1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Q7 Motor Setup
The parameters found in the Q7 Motor Setup contain basic and advanced motor data that are always necessary for configuring the
drive. This option also includes parameters for encoder setup.
Main Menu
The Main Menu mode is used to:
• List the parameter groups available to the drive and drive options.
• Change parameter values.
20 | Danfoss A/S © 2019.12
for the setup procedures.
Product Overview
Speed [RPM]
Motor Current
Power [kW]
Frequency
Reference %
