Operating Guide | VLT® AutomationDrive FC 302
Example:
1
2
3
4
1 Enclosure
3 M10 nut
5 Bolt at rear of pedestal
Illustration 11:
Pedestal to Enclosure Back Mounting Points
1
2
1 Enclosure
3 M10x30 fasteners (rear corner bolts not shown)
Illustration 12:
Pedestal to Enclosure Mounting Points
Danfoss A/S © 2019.12
5
6
2 Pedestal
4 Slotted hole in enclosure
6 Locking bracket
3
2 Pedestal
Mechanical Installation
AQ275652476278en-000101 / 130R0709| 29
