Operating Guide | VLT® AutomationDrive FC 302
9.8.3 E3h Exterior Dimensions
3X
13 (0.5)
1578
1537
(62.1)
(60.5)
1348
1
(53.1)
A
13 (0.5)
15 (0.6)
447
(17.6)
30
10 (0.4)
(1.2)
10 (0.4)
346 (13.6)
506 (19.9)
A
1 Disconnect option only
Illustration 61:
Front View of E3h
Danfoss A/S © 2019.12
AQ275652476278en-000101 / 130R0709| 151
