Operating Guide | VLT® AutomationDrive FC 302
7.1.8 Wiring Configuration: External Alarm Reset
Table 31: External Alarm Reset
Drive
+24 V
12
+24 V
13
D IN
18
D IN
19
COM
20
D IN
27
D IN
29
D IN
32
D IN
33
D IN
37
+10 V
50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
88 | Danfoss A/S © 2019.12
Parameter
Function
Parameter 5-11 Terminal 19 Digital Input
*=Default value
Notes/comments:
D IN 37 is an option.
Wiring Configuration Examples
Setting
[1] Reset
AQ275652476278en-000101 / 130R0709
