8.3.4 Status Messages - Operation Status

Table 39: Operation Status
Operation Description
status
AC brake AC brake was selected in parameter 2-10 Brake Function. The AC brake overmagnetizes the motor to achieve a con-
trolled slow down.
AMA finish Automatic motor adaptation (AMA) was carried out successfully.
OK
AMA ready AMA is ready to start. To start, press [Hand On].
AMA run- AMA process is in progress.
ning
Braking The brake chopper is in operation. The brake resistor absorbs the generative energy.
Coast • [2] Coast inverse was selected as a function for a digital input (parameter group 5–1* Digital Inputs). The corre-
sponding terminal is not connected.
• Coast activated by serial communication.
Ctrl. ramp- [1] Ctrl. ramp-down was selected in parameter 14-10 Mains Failure.
down
• The mains voltage is below the value set in parameter 14-11 Mains Voltage at Mains Fault.
• The drive ramps down the motor in a controlled manner.
Current The drive output current is above the limit set in parameter 4-51 Warning Current High.
high
Current low The drive output current is below the limit set in parameter 4-52 Warning Speed Low.
DC hold DC hold is selected in parameter 1-80 Function at Stop and a stop command is active. The motor is held by a DC
current set in parameter 2-00 DC Hold Current.
DC stop The motor is held with a DC current (parameter 2-01 DC Brake Current) for a specified time (parameter 2-02 DC Brak-
ing Time).
• DC brake is activated in parameter 2-03 DC Brake Cut In Speed [RPM] and a stop command is active.
• DC brake (inverse) is selected as a function for a digital input (parameter group 5–1* Digital Inputs). The corre-
sponding terminal is not active.
• The DC brake is activated via serial communication.
Feedback The sum of all active feedback is above the feedback limit set in parameter 4-57 Warning Feedback High.
high
Feedback The sum of all active feedback is below the feedback limit set in parameter 4-56 Warning Feedback Low.
low
Freeze out- The remote reference is active, which holds the present speed.
put
• [20] Freeze Output was selected as a function for a digital input (parameter group 5–1* Digital Inputs). The corre-
sponding terminal is active. Speed control is only possible via the terminal functions speed up and speed down.
• Hold ramp is activated via serial communication.
Freeze out- A freeze output command has been given, but the motor remains stopped until a run permissive signal is received.
put request
Freeze ref. [19] Freeze Reference was selected as a function for a digital input (parameter group 5–1* Digital Inputs). The corre-
sponding terminal is active. The drive saves the actual reference. Changing the reference is now only possible via
terminal functions speed up and speed down.
Jog request A jog command has been given, but the motor is stopped until a run permissive signal is received via a digital input.
