AC701 Evaluation Board Features
Table 1-26: HPC Connections, J30 to FPGA U1 (Cont'd)
J30 FMC1
Schematic Net Name
HPC Pin
J2
NC
J3
NC
J6
FMC1_HPC_HA03_P
J7
FMC1_HPC_HA03_N
J9
FMC1_HPC_HA07_P
J10
FMC1_HPC_HA07_N
J12
FMC1_HPC_HA11_P
J13
FMC1_HPC_HA11_N
J15
FMC1_HPC_HA14_P
J16
FMC1_HPC_HA14_N
J18
FMC1_HPC_HA18_P
J19
FMC1_HPC_HA18_N
J21
FMC1_HPC_HA22_P
J22
FMC1_HPC_HA22_N
J24
NC
J25
NC
J27
NC
J28
NC
J30
NC
J31
NC
J33
NC
J34
NC
J36
NC
J37
NC
J39
NC
Notes:
1. No I/O standards are associated with MGT connections.
Power Management
[Figure
The AC701 board uses power regulators and PMBus compliant system controllers from Texas
Instruments to supply core and auxiliary voltages. The Texas Instruments Fusion Digital Power GUI
is used to monitor the voltage and current levels of the board power modules.
The AC701 board power distribution diagram is shown in
62
Send Feedback
FPGA
J30 FMC1
I/O Standard
(U1) Pin
NA
NA
NA
NA
LVCMOS25
AC22
LVCMOS25
AC23
LVCMOS25
AD23
LVCMOS25
AD24
LVCMOS25
AD20
LVCMOS25
AE20
LVCMOS25
AE18
LVCMOS25
AF18
LVCMOS25
AA17
LVCMOS25
AB17
LVCMOS25
Y15
LVCMOS25
AA15
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
NA
1-2, callout 30]
