A.19 CTI interface signals
The processor supports various cross-trigger signals when it implements the CTI.
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
Non-Confidential
Signal Direction Description
CTICHIN[3:0] Input
CTICHOUTACK[3:0] Input
CTICHOUT[3:0] Output
CTICHINACK[3:0] Output
CISBYPASS Input
CIHSBYPASS[3:0] Input
CTIIRQ[CN:0] Output
CTIIRQACK[CN:0] Input
A Signal Descriptions

A.19 CTI interface signals

Table A-47 CTI interface signals
Channel In
Channel Out acknowledge
Channel Out
Channel In acknowledge
Channel interface sync bypass
Channel interface H/S bypass
CTI interrupt, active-HIGH
CTI interrupt acknowledge
