iC7 Series PROFINET
Operating Guide
Menu in- Parame-
dex ter name

4.3 GSDML (Device Description File)

To configure a PROFINET controller, the configuration tool needs a GSDML file for each type of device in the network. The GSDML
file is a PROFINET xml file containing the necessary communication setup data for a device. Each product in the iC7 series has a
unique GSDML file.
Download the GSDML files for the iC7 series from
figuration-files/. Check that the GSDML file version is compatible with the firmware version.

4.4 Reference Handling

The speed reference is scaled as a normalized relative value in percent (N2). The value is transmitted in hexadecimal:
• 0% = 0 hex
• 100% = 4000 hex
• -100% = C000 hex
Table 12: Reference Handling Parameters
Menu index Parameter
4.2.2.3 Nominal Speed
5.8.3.1 Positive Speed Limit
5.8.3.2 Negative Speed Limit
Reversing may be unwanted for certain applications.
-100%
(C000 hex)
Reverse
5.8.3.2
Negative Speed Limit
(rpm)
Illustration 10: Example of Fieldbus Speed Reference

4.5 General Connectivity Settings

General connectivity settings are in parameter group 10 Connectivity → Integrated Communication → Protocols → General Settings.
24 | Danfoss A/S © 2023.06
Parame- Value
ter num-
ber
- Lower case letters (a–z)
- Numbers (0–9)
- Special characters: dash (–), full stop (.)
The value can be up to 127 characters or digits in total.
The maximum length for each component separated
by a full stop or dash is 63 characters or digits. Spaces
are not allowed.
https://www.danfoss.com/en/service-and-support/downloads/dds/fieldbus-con-
0% 100%
(0 hex) (4000 hex)
Forward
Parameter number
402
1729
1728
5.8.3.1
Positive Speed Limit
(rpm)
PROFINET Configuration
Additional informa-
tion
Unit Range
[rpm] 0–100000
[rpm] 0–35400
[rpm] -35400–0
