TDE MACNO MINIOPD EXP User Manual page 86

2013 VAR UNSIGNED16
2014 VAR UNSIGNED16
2015 VAR UNSIGNED16
UNSIGNED
2016 VAR
2017 VAR UNSIGNED16
2018 VAR UNSIGNED16
2019 VAR UNSIGNED16
201A VAR INTEGER16
201B VAR INTEGER16
201C VAR INTEGER16
201D VAR INTEGER16
201E ARRAY INTEGER16
201F VAR UNSIGNED32
2020 VAR UNSIGNED32
2021 VAR UNSIGNED32
2022 VAR UNSIGNED16
2023 VAR UNSIGNED32
2024 VAR DOMAIN
4.2.6.1 FORMAT PARAMETERS TABLE (TAB_FORMAT 2001H)
This table is made by 800word (200*4) 4 words for each parameter :
st
1 word : it defines the parameter typology, its internal representation and the number of decimal and
integer digits which are shown up on the display. Each nibble has the following meaning:
0x 0 0 0 0 (in hexadecimal)
number of digits visualised in decimal
number of digits visualised in integer
internal representation :
Type of parameter:
For example:
0x1231 free parameter proportional to the base: the real value is = internal representation/base
th
(4 word).
nd
2 word : it defines the min. value admitted in the internal representation of the parameter
86
ingressi
ingressi_hw
uscite_hw
Tab_inp_dig_field
32
stato
allarmi
abilitazione_allarmi
f_fieldbus
limit_fieldbus
trif_fieldbus
theta_fieldbus
Tab_dati_applicazione
[100]
Ingressi_wr
Ingressi
Uscite_standard_rd
word_vuota
double_vuota
Tab_formati_extra
Logical status of the 8
inputs of the terminal board
Logical status of the 3
inputs from the power
Logical status of the 4 digit
outputs
Values set by CAN of the
output logical function
Variable of the drive's status
Drive alarms' status
Word for enabling drive's
alarms
Speed reference in % of
n in 16384
MAX
torque limit in % di Tnom in
4095
torque reference in % di
Tnom in 4095
Speed reference in electr.
pulses x Tpwm
Data Area available for the
application
Writing standard logical
inputs
Writing application logical
inputs
Reading standard inputs
Unused Word
Unused Double word
Formats of extra
parameters
0 Direct value
1 Percent of the base (100/base)
2 Proportional to the base (1/base)
3 Direct value unsigned
0 Not managed
1 free (changeable on-line)
2 Reserved (changeable off-line + key P60)
4 TDE (changeable off-line + key P99)
Reading
Reading
Reading
Reading/writing
Reading
Reading
Reading
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading/writing
Reading
Reading
Reading/writing
Reading/writing
Reading
